NEOxl 40
Backup and Archive Made Easy
NEOXL 40 3U 32-Slot Base 1-Drive LTO-7 Library SASOur Price: $8,964.00
NEOXL 40 3U 32-Slot Base 1-Drive LTO-7 Library FCOur Price: $9,921.00
NEOxl 40 3U 32-Slot Base 1-Drive LTO-8 Library SASOur Price: $9,876.00
NEOxl 40 3U 32-Slot Base 1-Drive LTO-8 Library FCOur Price: $11,238.00
More pricing below, click here
Overview:
Designed for enterprise applications experiencing rapid data growth, the NEOxl 40 delivers the ideal combination of features and functionality aimed at reducing the overall cost of your long-term data storage solutions.
- Capacity ranging from 120TB to 500TB
- Data transfer rates ranging from 504 GB/hr. to 8.6TB/hr.
- 6u form factor
- Scales up to 560 slots and 42 tape drives
- Removable cartridge magazines
- Support for Overland Storage LTFS solutions
NEO XL-Series libraries address the need for midrange and enterprise businesses to do more with less by providing effortless automated backup that combines flexibility, density, high-performance and affordability to ensure that data is protected faster, smarter, easier and more cost effectively.
With This Product You Can...
- Address small to medium enterprise backup and archive requirements with up to 513TB of data storage capacity
- Meet backup windows and improve efficiency with high-performance data transfer rates that range from 504 GB/hr. to 8.6TB/hr.
- Easily customize your capacity and performance to meet your data storage needs
- Reduce administrative costs with simplified configuration and management
- Lower your cost of ownership by reducing the amount of rack space, floor space, power and cooling typically needed for backup and archive applications
- Benefit from the convenience of disk-like “drag & drop” capabilities associated with LTFS
About the NEO XL-Series Family
Automated tape libraries deliver the ultimate in flexible, cost-effective backup, archive and disaster recoveryKeeping pace with today's incredible data growth rates is a significant challenge for IT professionals, especially when it comes to protecting that data seamlessly and affordably. The NEO XL-Series addresses the need for midrange and enterprise businesses to do more with less by providing effortless automated backup that combines flexibility, density, high-performance and affordability to ensure that data is protected faster, smarter, easier and more cost effectively.
Flexibility – Grow into, not out of, your storage
The scalable design of the NEO XL-Series allows customers to customize their backup and archive solution by starting out as a 6u, 60-slot, single-drive library and scaling to as many as 560 slots and 42 tape drives. The seamless design of NEOxl libraries allows you to add both data cartridges and tape drives as you scale, instead of requiring you to chose between capacity or performance.
Effortless expansion of your NEO XL-Series library occurs by simply connecting additional 6u modules, with a maximum of 7 modules in a standard 42" rack. Installation and configuration of additional modules is simplified with the use of either the webbased remote management interface or the touch-screen operator control panel.
The scalable design of NEOxl libraries not only allows users to easily scale the library into a larger configuration, but it also enables simplified redeployment of individual modules into smaller applications. This flexibility makes NEO XL-Series the most ideal, most cost-effective solution for any midrange or enterprise environment.
Simplicity – Minimize administrative overhead
NEO XL-Series libraries provide convenient, simplified installation, setup and operation with a touch-screen operator control panel or web-based remote management. Removable cartridge magazines facilitate the loading, unloading and off-line storage of data cartridges, reducing media handling costs. Meanwhile, mail slots provide easy, secure access to individual tape cartridges without interrupting library operations, while NEOxl tape drives are easily added, removed or replaced to ensure effortless upgradeability and serviceability.
Affordability – Get the best return on your investment
NEO XL-Series libraries are designed to not only provide an affordable purchase price, but to deliver superior long-term cost of ownership. NEO XL-Series ease-of-use features and enterprise-class reliability ensure administrative, support and downtime costs are virtually eliminated, while the native partitioning functionality provides the ability to utilize a single library in a variety of applications.
Dependability – Backup and archive you can count on
NEO XL-Series libraries provide the reliability required by today's demanding IT environments to ensure that your data is readily accessible and always available. Features such as redundant power provide access to your data in the event of a power disruption, while easily replacable tape drives and tape library modules ensure seamless reconfiguration should a support event occur and require replacement.
All NEO XL-Series libraries are covered by a standard one-year, next business day onsite warranty. For customers requiring a higher level of onsite support, customers may upgrade to enhanced next-business day support or 24x7x4 hr response times for the most mission critical operations.
NEO XL-Series tape libraries provide the ultimate in automated data backup, archiving and disaster recovery by delivering the flexibility, affordability and dependability required for midrange and enterprise-class operations.
Features:
 |
Remote ManagementNEO XL-Series remote management provides intelligent, proactive administration and monitoring of the tape library, tape drives and media, ensuring a seamless backup and archive process. |
|
Highlights
|
Why You Need It...
|
|
 |
Expandability/ScalabilityNEO Series expandability/scalability features allow you to dynamically adjust your storage capacity and performance as your data storage needs change, adapting to ever-changing environments with a minimal amount of disruption while protecting your original library investment. |
|
Highlights
|
Why You Need It...
|
|
 |
Removable Cartridge MagazinesNEO XL-Series removable cartridge magazines provide effortless media handling for loading/unloading of cartridges while facilitating off-line storage for disaster recovery purposes. |
|
Highlights
|
Why You Need It...
|
|
 |
Upgradable Tape DrivesAvoid those costly upgrades when new tape technologies become available. With NEO XL-Series libraries, you can upgrade your drives and media on the fly. Installing and removing tape drives in is quick and easy. LTO drives maintain backward compatibility to previous generation tapes, so you won’t orphan any data during the upgrade process. This approach not only protects your investment, but also minimizes administrative overhead, and reduces service/maintenance costs. |
|
Highlights
|
Why You Need It...
|
|
 |
PartitioningNEO XL-Series partitioning capability allows you to configure a single physical library into multiple virtual libraries. |
|
Highlights
|
Why You Need It...
|
|
.jpg) |
Effortless Installation and ConfigurationSimplified installation and configuration improves efficiency and reduces administrative overhead by ensuring that you can begin your backup and archive process quickly. |
|
Highlights
|
Why You Need It...
|
|
 |
Superior DensityThe ability to store the maximum amount of data in the minimal amount of rack space ensure the best value for your IT budget. |
|
Highlights
|
Why You Need It...
|
|
 |
Proven ReliabilityEnterprise-class reliability ensures the availability of your company’s most valueable asset … your corporate data. |
|
Highlights
|
Why You Need It...
|
|
Technical Specifications:
| NEOxl 40 | |
| # of tape cartridge slots (base) | 32 |
| # of tape cartridge slots (expansions) | 40 |
| # of tape cartridge magazines (base) | 2 |
| # of tape cartridge slots per magazine (base) | 20 |
| # of mail slots (base) | Up to 3 |
| # of tape drives (base) | Up to 3 HH |
| # of tape drives (expansions) | Up to 3 HH |
| Tape drives supported | LTO-8, LTO-7 |
| max. # of modules supported | 7 |
| max. # of cartridge slots* | 272 |
| max. # of tape drives* | 21 |
| Max. native capacity per module (TB) | LTO-8: 400TB LTO-8M: 300TB LTO-7: 200TB |
| Max. compressed capacity per module (TB) | LTO-8: 1PB LTO-8M: 700TB LTO-7: 500TB |
| Max. native capacity - fully scaled (TB) | LTO-8: 3.3PB LTO-8M: 2.4PB LTO-7: 1.6PB |
| Max. compressed capacity - fully scaled (TB) | LTO-8: 8.2PB LTO-8M: 6.1PB LTO-7: 4.1PB |
| Max. native data transfer rate per module (TB/hr.) | LTO-8: 3.2TB/hr. LTO-8M: 3.2TB/hr. LTO-7: 3.2TB/hr |
| Max. compressed data transfer rate per module (TB/hr.) | LTO-8: 8.1TB/hr. LTO-8M: 8.1TB/hr. LTO-7: 8.1TB/hr. |
| Max. native data transfer rate - fully scaled (TB/hr.) | LTO-8: 22.7TB/hr. LTO-8M: 22.7/hr. LTO-7: 22.7TB/hr. |
| Max. compressed data transfer rate - fully scaled (TB/hr.) | LTO-8: 56.7TB/hr. LTO-8M: 56.7TB/hr. LTO-7: 56.7TB/hr. |
| Interfaces | 6Gb SAS, 8Gb FC (dual port) |
| Connectors | Mini SAS, LC Optical FC |
| Form Factor | 3u |
| Dimensions (inches) | 5.24" x 18.98" x 34.27" |
| Dimensions (cm) | 13.3cm x 48.2cm x 87.3cm |
| Weight (pounds) | 55.34 lbs. |
| Weight (Kg) | 21.1 kg |
| Power Requirements | 230 watts (nominal) |
| Input Requirements | 100 to 240 V, 50 to 60 Hz |
| Humidity (non-condensing; operating) | 20% to 80% RH non-condensing |
| Temperature range (operating) | 10° to 35°C |
| Reliability | >2,000,000 MCBF (mean cycles between failures); <10 minutes MTTR (mean time to repair) |
| Safety | CB, CE, NRTL |
| Emissions | CE, FCC, ICES, EMC/EN, CCL, ETL |
| Standard Warranty | NEOxl 40 libraries include a one-year Silver Support Program warranty offering, which includes 5x9 telephone support and NBD onsite support of FRUs, with customer replacement of CRUs |
Documentation:
Download the NEO XL-Series Datasheet (PDF).
Pricing Notes:
- Snap Servers require that replacement drives be of the same capacity as those originally installed in the system. Please verify the capacity of your original Snap Server drives before purchasing any replacement drive.
- Overland CARE support Upgrades (Part Number EWCARExU-xxx) are valid only on new products within the first 90 days following purchase and start at the date of installation.
- Snap Server systems are eligible for enhanced Overland CARE maintenance options to augment the standard limited warranty.
- Specially priced 5 year Overland CARE support upgrades are available to protect your investment for the life of the product.
- All Snap Server systems products, now also include Software Maintenance for the full term of the factory warranty.
- Support coverage of all Snap Expansion units must be purchased separately and run concurrently with the primary Unit.
- You may augment your support with our Overland ACCESS support option for 24x7 access to our expert technical support team or with our Secure Drive program which allows you to keep your failed disk drives in secure data environments.
NEOXL 40 3U 32-Slot Base 1-Drive LTO-7 Library SASOur Price: $8,964.00
NEOXL 40 3U 32-Slot Base 1-Drive LTO-7 Library FCOur Price: $9,921.00
NEOxl 40 3U 32-Slot Base 1-Drive LTO-8 Library SASOur Price: $9,876.00
NEOxl 40 3U 32-Slot Base 1-Drive LTO-8 Library FCOur Price: $11,238.00
