Overview:
Overland Tandberg Data has been renowned for its high-quality products for many years and Overland Tandberg Data media is subject to stringent quality controls and measurement in order to ensure quality and reliability. LTO (Ultrium™), the most popular tape technology, is a high-performance tape technology offering versatility, reliability and performance.
Overland Tandberg Data Tape Media and storage products are the result of many years of joint development and continuous enhancements. This helps to meet the increasing capacity, performance and cost-efficiency demands. The industry-leading quality and reliability of our products is acknowledged by leading international OEM customers. Our partners are dependent on optimum data security for their mission critical data storage needs. Using Overland Tandberg Data branded media with Overland Tandberg Data branded storage products assures industry-leading performance and data security. Overland Tandberg Data media is always the right choice because it is designed to work with our products. To achieve and maintain the maximum benefit of your Overland Tandberg Data branded storage product, we recommend to use Overland Tandberg Data media cartridges with them.
Reliability
Use Overland Tandberg Data media to assure Overland Tandberg Data quality. Overland Tandberg Data cartridges allow users to perform 200 complete backups and archive data for more than 30 years.
Specifications:
| Specifications: | |||||
|---|---|---|---|---|---|
| LTO Media Compatibility | |||||
| TAPE FORMAT | LTO-3 | LTO-4 | LTO-5 | LTO-6 | LTO-7 |
| LTO-2 | R/W | R | |||
| LTO-3 | R/W | R/W | R | ||
| LTO-4 | R/W | R/W | R | ||
| LTO-5 | R/W | R/W | R | ||
| LTO-6 | R/W | R/W | |||
| LTO-7 | R/W | ||||
| Basic Specifications | |||||
| Storage Capacity | 400GB / 800GB* | 800GB / 1600GB* | 1.5TB / 3.0TB* | 2.5TB / 6.25TB* | 6TB / 15TB* |
| Transfer Rate | Up to 120 MB/s* | Up to 240 MB/s* | Up to 280 MB/s* | Up to 400MB/s* | Up to 750MB/s* |
| Number of Tracks | 704 | 896 | 1280 | 2176 | 3584 |
| Cartridge Memory | 4KB | 8KB | 8KB | 16KB | 16KB |
| HH Drive Data Buffer | 128MB | 128MB | 256MB | 512MB | 1024MB |
| Magnetic Properties | |||||
| Magnetic Particle | Super Finavinx (Metal) | Super Finavinx (Metal) | Super Finavinx (Metal) | Super Finavinx (Metal) | Barium Ferrite |
| Linear Recording Density | 9.64kbpmm | 12.72kbpmm | 14.68kbpmm | 15.14kbpmm | 19.09kbpmm |
| Dimensions | |||||
| Cartridge Dimensions | 102.0 × 105.4 × 21.5mm | 102.0 × 105.4 × 21.5mm | 102.0 × 105.4 × 21.5mm | 102.0 × 105.4 × 21.5mm | 102.0 × 105.4 × 21.5mm |
| Tape Width | 12.65mm | 12.65mm | 12.65mm | 12.65mm | 12.65mm |
| Tape Thickness | 8µm | 6.6µm | 6.4µm | 6.4µm | 5.6µm |
| Tape Length | 680m | 820m | 846m | 846m | 960m |
| Operating Environment | |||||
| Temperature | 10° - 45°C | 10° - 45°C | 10° - 45°C | 10° - 45°C | 10° - 45°C |
| Humidity | 10 - 80%** | 10 - 80%** | 10 - 80%** | 10 - 80%** | 10 - 80%** |
| Maximum Wet Bulb Temp. | 26°C | 26°C | 26°C | 26°C | 26°C |
| Storage Environment | |||||
| Temperature (Short-term) | 16° - 32°C | 16° - 35°C | 16° - 35°C | 16° - 35°C | 16° - 35°C |
| Temperature (Archive) | 16° - 32°C | 16° - 25°C | 16° - 25°C | 16° - 25°C | 16° - 25°C |
| Humidity (Short-term) | 20 - 80%** | 20 - 80%** | 20 - 80%** | 20 - 80%** | 20 - 80%** |
| Humidity (Archive) | 20 - 80%** | 20 - 50%** | 20 - 50%** | 20 - 50%** | 20 - 50%** |
| Media Life | |||||
| Durability (Nominal) | 1,000,000 passes | ||||
| Archival-Life | 30 years | ||||
| Warranty | Limited lifetime warranty (typically 30 years) | ||||
Benefits:
- High Capacity
Up to 15TB* of data on a single cartridge - Leading Performance
Up to 2.7 TB/hr* reducing backup and restore times - Reliability
Stringent testing ensures maximum reliability - Flexibility
A choice of media products and services including barcode labeling and library packs - Lowest Storage Cost
LTO media delivers the lowest storage cost/GB of any media - Archiving
LTO media archival life of 30 years - Warranty
Limited lifetime warranty (typically 30 years)
* Assumes compression ratio of 2:1 on LTO-3/4/5 & 2.5:1 on LTO-6/7
Documentation:
Download the Overland Tandberg Data LTO Media Datasheet(PDF).
